Commercial

Commercial Fixed Windows

$414.00 - $618.00 / sq m Excluding GST

ENTER ALUMINIUM SIZES Read More

Transom 600H

Total Area (sq m)
Product Price

Colour *

Select Your Powder Coat Finish

Selected Pearls

Lead Time *

Select Express If You Need It ASAP

Glazing *

Select Your Glass For Thermal Efficiency And Safety
NOTE: BAL 19,29 & 40 Bush Fire Areas Require 6mm Toughened Glass
NOTE: Windows Below 500mm From Floor Require Toughened Glass
NOTE: Windows In Bathrooms Require Toughened Glass
*DG Tgh= Double Glazed Toughened – *Low E = Low Emissivity
*U= U value – *SHGC= Solar Heat Gain Coefficient

Reveals

Select Your Pre Primed Timber Reveals To Suit Your Construction
NOTE: Reveals Adds H40mm & W40mm To Aluminium Sizes Entered

Special Reveal

Closer Trim

Select Closer Trim To Make Window In Line
NOTE: Reveal & Closer Trim Adds H43mm & W43mm To Aluminium Sizes Entered

TRANSOM HEIGHT

Select To Enter Custom Transom Height
NOTE: Default Transom Height is 600mm Bottom Aluminum To Center Transom
NOTE: Size Is Approximate From Bottom Aluminium To Center of Transom

Protection

Select Your Protective Wrap
NOTE: Protection Applied To External Glass & Aluminium Frame Only

Installation

Select If You Require Installation
NOTE: Installation Is Subject To Site Inspection
NOTE: Windows Above 800mm Require Scaffolding
NOTE: Added $320.00 Service Fee If Less Than 2 Items Installed

Internal Architraves

Select If You Require Internal Architraves
NOTE: To Match Existing Architraves Select Custom Architraves
NOTE: Ensure You Provide Sufficient Amount Of Custom Architraves

Disposal

Select If You Require Disposal Of Existing Windows

Description

Commercial Architectural Fixed Windows windows are made easy at EZ Windows!

Designer Series  | Series 424 Frame without sash.(click to download)

Commercial Fixed Window Brochure

Series 424 CentreGLAZE™ shopfront framing measures 102mm x 50mm and has been designed specifically to accept 24mm Insulating Glass Units (IGUs).

  • The 28mm deep glazing pocket is designed to accept thick heavy IGUs and allows glass to be installed easily with room to spare (catering for glass manufacturing tolerance).
  • This deep glazing pocket provides a 12mm bite as required by the IGU manufacturers and ensures compliance with glass warranties.
  • Reinforced tall glazing bead at sill tolerate high wind loads.
  • True captive glazing wedge allows reglazing from inside – ideal in elevated applications.
  • The captive wedge also offers increased security.
  • Glazing wedges are recessed into the framing for a clean aesthetic.
  • Wide range of sub-sills to cover most installations, including sub-sills with integrated nailing fin ideal for residential installations.
  • Sub-head and two piece sub-jambs.
  • Numerous door thresholds including weather resisting thresholds for external and internal swing doors.
  • Designed for use with Series 50, 51 and 52 commercial doors.
  • Compatible with Commercial and Architectural Series systems.
  • Accepts awning and Casement sashes.

Additional information

Weight 405 kg
Glass Selection

5mm Clear Glass (U6.4 SHGC 0.73), 5mm Toughened Glass (U6.4 SHGC 0.73), Double Glazed (U4.2 SHGC 0.58)
